Fresenius 5008S CorDiax haemodialysis system
A Fresenius dialysis system designed to make high-volume online haemodiafiltration (HDF) as easy as standard haemodialysis. Milap International supplies, installs and services the 5008S CorDiax as an authorised Fresenius partner.
- Online HDF and high-flux haemodialysis
- 30–600 mL/min blood flow range
- Up to 1,000 mL/min dialysate flow
- 15-inch touchscreen rotatable and tiltable
What is the Fresenius 5008S CorDiax?
The Fresenius 5008S CorDiax is a haemodialysis system from the 5008 CorDiax series that runs both high-flux haemodialysis and online haemodiafiltration (HDF). With options such as AutoSub plus and ONLINEplus it produces substitution fluid online and maximises the convective volume automatically, so dialysis centres can offer high-volume HDF as routine care.
Key features
Online HDF
Haemodialysis and online haemodiafiltration on one machine.
AutoSub plus (option)
Automatically sets the highest suitable substitution volume for high-volume HDF.
ONLINEplus (option)
Prepares sterile, bicarbonate-buffered substitution fluid online.
AutoFlow and EcoFlow
Adjust dialysate flow to the effective blood flow and reduce fluid and energy use.
Venous Access Monitoring
Watches the venous line to help detect needle dislodgement early.
OCM, DIASAFE plus and bibag
Online clearance monitoring, ultrapure fluid and dry bicarbonate.
How a treatment runs on the 5008S CorDiax
- Prime the extracorporeal circuit, using online priming where configured.
- Choose haemodialysis or online HDF and enter the prescription.
- Treat the patient while AutoSub plus sets the substitution volume and Venous Access Monitoring watches the venous line.
- End with online reinfusion of the blood and run the disinfection programme.
Specifications
| Specification | Fresenius 5008S CorDiax |
|---|---|
| Therapies | High-flux haemodialysis and online haemodiafiltration |
| Blood flow | 30–600 mL/min (±10%) |
| Dialysate flow | 0–1,000 mL/min |
| Substitution rate | 25–600 mL/min |
| Ultrafiltration rate | 0–4,000 mL/h, ±1% |
| Dialysate temperature | 34–39 °C |
| Conductivity | 12.8–15.7 mS/cm |
| Display | 15-inch (38 cm) touchscreen |
| Options | BTM, BVM, BPM, AutoSub plus, ONLINEplus |
| Dimensions (H × W × D) | 1,680 × 350 × 780 mm |
| Weight | About 100 kg |
| Power | 100–240 V AC, 47–63 Hz |
Download the official Fresenius 5008S haemodialysis system brochure (PDF, 3 MB)
Source: Fresenius Medical Care 5008 CorDiax product overview. Options vary by configuration; ask us for the Indian configuration.
Who is the 5008S CorDiax for?
The 5008S CorDiax suits dialysis centres and hospitals that want to offer online haemodiafiltration as standard care, as well as units upgrading from older haemodialysis machines.
Compare Fresenius systems
| System | Therapy | Typical setting |
|---|---|---|
| 4008S NG | Haemodialysis | Dialysis units and hospital nephrology |
| 5008S CorDiax | Haemodialysis and online HDF | Dialysis centres moving to HDF |
| multiFiltratePRO | CRRT, citrate anticoagulation, plasma exchange | Intensive care units |
| Xenios ECMO | VV and VA ECMO, ECCO2R | Cardiac and respiratory ICUs |
Installation, training and service
Installation and commissioning
Site, water and electrical checks, set-up and first-run support by Milap engineers.
Clinical application training
Hands-on training for nurses, technicians and doctors.
Consumables and spares
Genuine Fresenius consumables and spare parts supplied from Bengaluru.
AMC, CMC and breakdown support
Preventive maintenance plans, with breakdown calls answered during evenings and weekends.
Related products
Haemodialysis machine for dialysis units.
CRRT system for intensive care.
ECMO and ECLS platform.
Related guide
Space, water, machines, staff and service.
Frequently asked questions
Yes. It runs high-flux haemodialysis and online haemodiafiltration, single- or double-needle.
Up to 600 mL/min.
Yes, with the ONLINEplus option the machine prepares sterile substitution fluid from the dialysis fluid.
An option that automatically sets the highest suitable substitution volume during HDF, so teams do not need to calculate it manually.
The 4008S NG is a haemodialysis machine. The 5008S CorDiax adds online HDF, a larger touchscreen and automated features such as AutoFlow.
Yes. Milap engineers install and commission the system, train your team, supply genuine consumables and spares, and offer preventive maintenance, AMC or CMC with breakdown support from Bengaluru.
Milap International, based in Bengaluru, is an authorised channel partner and supplies the Fresenius 5008S CorDiax haemodialysis system to hospitals, laboratories and clinics across Karnataka, with installation, training and service from the same team.
The price depends on the model, configuration, accessories and service terms you choose. Request a quote with your requirement and a product specialist will reply with a written price within 24 hours.
Get a quote for the Fresenius 5008S CorDiax
Tell us about your dialysis unit and HDF plans, and we will send pricing and a service plan.
