Sysmex CA-600 series automated coagulation analyzer
A compact, fully automated Sysmex coagulation analyzer for PT, APTT, fibrinogen, D-dimer and specialty tests in true random access. Milap International supplies, installs and services the CA-600 series as an authorised Sysmex partner.
- Up to 60 PT tests/hour 42 tests/hour for PT, APTT and Fbg
- 5 tests at once true random access
- Clotting, chromogenic, immunoassay on the CA-660
- 566 × 490 × 490 mm compact benchtop footprint
What is the Sysmex CA-600 series?
The Sysmex CA-600 series is a compact, fully automated coagulation analyzer for mid-volume labs. It uses optical scattered-light detection for clotting tests such as PT, APTT and fibrinogen and, on the CA-660 model, adds chromogenic and immunoassay tests including D-dimer, running up to five different tests at the same time in true random access.
Key features
Broad test menu
PT, APTT, fibrinogen, TT, factor assays, lupus anticoagulant screen and confirm, and on the CA-660 antithrombin, D-dimer and vWF tests.
True random access
Programme up to 14 test protocols and run up to 5 different tests at the same time.
On-demand STAT
Urgent samples can be run as soon as they arrive.
Auto-dilution
Automatic dilution for accurate results with abnormal fibrinogen or D-dimer levels.
Reaction curve review
View the reaction curve for each result to support correct interpretation.
Built-in quality control
X-bar and L-J control programmes, plus bi-directional LIS connection.
How a coagulation test runs on the CA-600
- Collect blood in a light-blue sodium citrate tube, filled to the correct level, and centrifuge it to get plasma.
- Place the sample on the analyzer; the probe with a liquid-level sensor aspirates plasma and reagents.
- The sample is incubated at 37 °C and the detector measures clot formation by scattered light, or colour or turbidity change for chromogenic and immunoassay tests.
- Results and reaction curves appear on the touchscreen and print on the built-in printer or go to your LIS.
Specifications
| Specification | Sysmex CA-600 series |
|---|---|
| Analyzer type | Fully automated coagulation analyzer |
| Principles | Clotting: scattered light detection; chromogenic: colorimetric; immunoassay: latex-enhanced turbidimetric (CA-660) |
| Parameters | Clotting: PT, APTT, Fbg, TT, Batroxobin time, Protein C, LA screen and confirm, factor assays (FII, FV, FVII, FVIII, FIX, FX, FXI, FXII); chromogenic: ATIII, plasminogen, α2-antiplasmin, Protein C, heparin; immunoassay: D-dimer, P-FDP, vWF Ag, vWF Ac |
| Test protocols | 14 programmable; 5 in random access at the same time |
| Throughput | Up to 60 tests per hour (PT only); 42 tests per hour (PT, APTT, Fbg) |
| Sample volume | PT, APTT, TT: 50 µL; Fbg, ATIII: 10 µL; factor assays: 5 µL; D-dimer: 8 µL |
| Reaction tubes | 60 (2 racks of 30) |
| Reagent station | 4 cooled holders (15 ± 2 °C) |
| Data storage | 600 samples (up to 3,000 tests) |
| Display | 4.5 × 3.4 inch colour LCD touch panel; built-in printer |
| Dimensions and weight | 566 × 490 × 490 mm (W × H × D); 42 kg |
| Power | 100–240 V AC, 50/60 Hz; 300 VA or less |
Download the official Sysmex CA-600 series coagulation analyzer brochure (PDF, 1 MB)
Source: Sysmex Asia Pacific CA-600 series brochure. Chromogenic and immunoassay tests and the built-in barcode reader are on the CA-660 model.
Who is the CA-600 series for?
The CA-600 series suits hospital labs, diagnostic centres and blood banks with a mid-volume coagulation workload, including pre-operative screening, anticoagulant monitoring and bleeding investigations. Choose the CA-620 for routine clotting tests, or the CA-660 to add D-dimer, antithrombin and other chromogenic and immunoassay tests on the same analyzer.
CA-620 or CA-660?
| Feature | CA-620 | CA-660 |
|---|---|---|
| Clotting tests (PT, APTT, Fbg and more) | Yes | Yes |
| Chromogenic tests | No | Yes |
| Immunoassay tests (D-dimer) | No | Yes (575 nm) |
| Reagent cooler | Yes | Yes |
| Built-in barcode reader | Optional | Yes |
| Handheld barcode reader | Optional | Optional |
Installation, training and service
Installation and commissioning
Site checks, set-up, calibration and first-run verification by Milap engineers.
Application training
Hands-on training for technicians on daily runs, QC and maintenance.
Reagents and controls
Genuine Sysmex reagents and controls supplied from Bengaluru.
AMC, CMC and breakdown support
Preventive maintenance plans, with breakdown calls answered during evenings and weekends.
Related products
Compact analyzer with an automated sample loader.
High-throughput analyzer for large labs.
Compact analyzer with RET and body fluid options.
Related guide
How to choose a coagulation analyzer
Test menu, methods and sample handling.
Frequently asked questions
Clotting tests such as PT/INR, APTT, fibrinogen, TT and factor assays on both models. The CA-660 also runs chromogenic tests such as antithrombin and immunoassays such as D-dimer.
The CA-620 runs clotting tests only. The CA-660 adds chromogenic and immunoassay tests and has a built-in barcode reader.
Up to 60 tests per hour for PT alone, or 42 tests per hour when running PT, APTT and fibrinogen together.
Yes. It has on-demand STAT capability, so urgent samples can be run as soon as they arrive.
Coagulation tests use citrated plasma from light-blue sodium citrate tubes, filled to the correct level and centrifuged before testing.
Yes. Milap engineers install and commission the analyzer, train your staff, supply genuine reagents and controls, and offer preventive maintenance, AMC or CMC with breakdown support from Bengaluru.
Milap International, based in Bengaluru, is an authorised channel partner and supplies the Sysmex CA-600 series automated coagulation analyzer to hospitals, laboratories and clinics across Karnataka, with installation, training and service from the same team.
The price depends on the model, configuration, accessories and service terms you choose. Request a quote with your requirement and a product specialist will reply with a written price within 24 hours.
Get a quote for the Sysmex CA-600 series
Tell us your daily coagulation test volume and test menu, and we will send pricing, reagent costs and a service plan.
