AVE-772 fully automated urine analyzer
An integrated urine analyzer that runs physical, dry-chemistry and AI-assisted sediment microscopy tests from one sample. Milap International supplies and services the AVE-772, available in India through Matrix.
- 3-in-1 physical, chemistry and sediment
- 14 chemistry items including mALB and creatinine
- Over 95% AI recognition accuracy
- Closed tube cap-piercing sampling
What is the AVE-772?
The AVE-772 is a fully automated integrated urine analyzer from AVE Science & Technology. From one sample intake it measures physical properties, runs a 14-item dry-chemistry strip and identifies formed elements such as red and white cells, epithelial cells, casts and crystals using AI machine vision and automatic microscopy.
Key features
Integrated testing
Physical, chemical and sediment tests from one sample intake.
AI microscopy
Machine vision with autofocus and automatic switching between high and low magnification.
Broad chemistry
14 items, including microalbumin, creatinine, calcium and ascorbic acid.
Physical parameters
Colour, turbidity, specific gravity, conductivity and osmolality.
Closed-tube sampling
Sealed collection tubes with cap-piercing sampling.
Real images
Real cell images with standardised classification and counting.
How a urine test runs on the AVE-772
- Load capped urine tubes in racks.
- The analyzer pierces the cap and draws the sample.
- It runs strip chemistry, physical measurements and AI microscopy of the sediment.
- Review the combined report with images and send it to the LIS.
Specifications
| Specification | AVE-772 |
|---|---|
| Analyzer type | Fully automated integrated urine analyzer |
| Manufacturer | AVE Science & Technology |
| Physical tests | Colour, turbidity, specific gravity, conductivity, osmolality |
| Chemistry (14 items) | BLD, LEU, SG, pH, GLU, PRO, NIT, KET, URO, BIL, VC, mALB, CR, Ca |
| Formed elements | RBC, WBC, epithelial cells, casts, crystals |
| Microscopy | AI machine vision with automatic microscopy |
| Recognition accuracy | Over 95% |
| Sampling | Closed tube, cap piercing |
| Throughput | Chemistry up to 240 tests/hour; microscopy up to 120 tests/hour |
| Sample loading | 60 samples |
| Sample volume | 3 mL |
| Data storage | Over 200,000 results |
| LIS/HIS | Bidirectional interface |
Download the official Matrix AVE-772 urine analyzer brochure (PDF, 3 MB)
Source: AVE Science & Technology and Matrix AVE-772 product pages. Ask us for the current Indian configuration.
Who is the AVE-772 for?
The AVE-772 suits hospital and diagnostic-centre labs that want urine chemistry and sediment microscopy automated in one instrument, reducing manual microscopy.
Compare urine analyzers
| Analyzer | Type | Best for |
|---|---|---|
| AVE-772 | Fully automated chemistry + AI sediment microscopy | Busy hospital and diagnostic labs |
| CLINITEK Advantus | Semi-automated urine chemistry | Mid-volume labs |
| CLINITEK Status+ | Compact urine chemistry | Clinics and point of care |
Installation, training and service
Installation and commissioning
Site checks, set-up, calibration and first-run verification by Milap engineers.
Application training
Hands-on training for technicians on daily runs, QC and maintenance.
Reagents and controls
Genuine AVE reagents and controls supplied from Bengaluru.
AMC, CMC and breakdown support
Preventive maintenance plans, with breakdown calls answered during evenings and weekends.
Related products
Semi-automated urine chemistry analyzer.
Compact urine chemistry analyzer.
Related guide
How to choose a urine analyzer
Strip reader, semi-automated or fully automated.
Frequently asked questions
Yes, using AI machine vision and automatic microscopy.
14, including microalbumin, creatinine and calcium.
Colour, turbidity, specific gravity, conductivity and osmolality.
The manufacturer states over 95%.
No. It samples closed tubes by piercing the cap.
Yes. Milap engineers install and commission the analyzer, train your staff, supply genuine reagents and controls, and offer preventive maintenance, AMC or CMC with breakdown support from Bengaluru.
Milap International, based in Bengaluru, is an authorised channel partner and supplies the AVE-772 fully automated urine analyzer to hospitals, laboratories and clinics across Karnataka, with installation, training and service from the same team.
The price depends on the model, configuration, accessories and service terms you choose. Request a quote with your requirement and a product specialist will reply with a written price within 24 hours.
Get a quote for the AVE-772
Tell us your daily urine sample volume and we will send pricing and a service plan.
